Unify Ultra
Technical Information
Model
Unify Ultra U02-21A
Operating Systems
Windows 11
Android 14
Android 14
Processors
Intel® Core™ i7-13 Gen
ARM Cortex-A76 8 Cores 2.4GHz
(Both processors work simultaneously)
ARM Cortex-A76 8 Cores 2.4GHz
(Both processors work simultaneously)
Graphics
Intel® Iris Xe Graphics
Screen
165 inches
4K (3840 x 2160) COB LED
Pixel pitch of 0.9mm
3840 Hz refresh rate
450 Nits
170° viewing angle
4K (3840 x 2160) COB LED
Pixel pitch of 0.9mm
3840 Hz refresh rate
450 Nits
170° viewing angle
Memory
16GB LPDDR4
Storage
SSD de 1 TB M.2 NVMe™
I/O Ports
4x USB 2.0
3x USB 3.0
1x USB B
2x HDMI In
2x HDMI Out
1x Ethernet In
1x Ethernet Out
1x 3.5mm audio output connector
1x 3.5mm audio input connector
3x USB 3.0
1x USB B
2x HDMI In
2x HDMI Out
1x Ethernet In
1x Ethernet Out
1x 3.5mm audio output connector
1x 3.5mm audio input connector
Touch
10-point simultaneous touch system, 12ms response speed
Physical Sides
Choose between white ceramic sides or chalkboard, both options have a suit of physical quick access for equipment functions
Power
Peak power consumption: ≤2400 W
Standby power: ≤0.5W
Input: 100~240 V AC, 50/60 Hz
Standby power: ≤0.5W
Input: 100~240 V AC, 50/60 Hz
Dimensions and Weight
Height: 2.22m
Width: 7.65m
Thickness: 0.22m
Weight: 358kg
Width: 7.65m
Thickness: 0.22m
Weight: 358kg
Environmental Requirements
Operating Temperature: -10 ℃ ~ 45 ℃
Humidity: 10～ 90%
Humidity: 10～ 90%
Languages
English (United States), Spanish (Mexico) and Italian
Warranty
5-year warranty on manufacturing defects and software
Priority Technical Support
Rapid response line
Via (WhatsApp, Email and Signal)
Via (WhatsApp, Email and Signal)
Security
Trusted Platform Module (TPM) 2.0
Items Included in the Box
Power cables
Maintenance tools
Maintenance tools
